Most compressed gas cylinders require the installation of at least one cylinder valve. This valve allows the cylinder to contain gases and gas to be filled or emptied from the cylinder. The cylinder valve is the most vulnerable part of the compressed gas package and requires a thorough understanding to maximize its performance. There are four basic valve types: the pressure seal valve, the packed valve, the O ring valve, and the diaphragm valve. There are several versions or designs within each of the four basic types. This pamphlet will address the more common valves in today’s industry.
What a Cylinder Valve Does?
Cylinder valves are crucial components that control the release of gas from pressurized cylinder and containers. They guarantee that gas is released safely, in the proper quantities, and at the appropriate pressure for its intended use. Handling gases in industrial, medical, and commercial contexts would be dangerous and inefficient without these valves. We build each valve with unique tasks that guarantee safety, accuracy, and dependability.
Flow Control
All cylinder valves provide precise control over gas flow, which is critical in applications that demand a constant gas supply. For example, a steady flow is required to produce clean, high-quality welds when welding with inert gases such as argon. Some valves automatically adjust flow based on specified pressure levels. Others contain manual controls that allow the user to fine-tune the flow to match the task’s requirements. When shifting from more minor to more significant welds, a welder may increase the flow to provide sufficient shielding. This ability to govern the flow leads to a smooth, efficient operation.
Pressure Regulation
Cylinder valves control gas flow and pressure. This is especially important in medical applications such as oxygen therapy, where precise pressure is essential to ensure patients receive the proper amount. Too much pressure can ruin equipment, while too little can render the gas ineffectual. To circumvent these issues, many cylinder valves include built-in pressure regulators that keep the correct pressure for safe and efficient operation. Could you imagine a medical oxygen system without this feature? It would be hazardous and unpredictable.
Safety Mechanisms
Safety is crucial when working with pressurized gases, and cylinder valves incorporate various safety mechanisms to reduce dangers. One of the most vital parts is the pressure relief valve, which automatically releases gas when the internal pressure rises above acceptable levels. This is especially important during shipping, as external variables like temperature fluctuations or complex handling can result in severe over-pressurization.
Emergency Shutoff
All industrial and medicinal gas cylinders have emergency shutdown capabilities, which allow users to quickly stop the flow of gas in the event of a leak or failure. This feature is standard on all industrial and medicinal gas cylinders, and it is important because it can prevent fires, explosions, and toxic gas exposure in high-risk areas like laboratories or industrial sites.
Types of Cylinder Valves
Pressure Seal valves
Pressure seal construction is adopted for Valves for high pressure service, typically in excess of above 170 bar. The unique feature about the pressure seal Bonnet is that the body-Bonnet joints seals improves as the internal pressure in the Valve increases, compared to other constructions where the increase in internal pressure tends to create leaks in the body-Bonnet joint.
Diaphragm Valve
A diaphragm is a flexible, pressure responsive element that transmits force to open, close or control a valve. Diaphragm valves are related to pinch valves, but use an elastomeric diaphragm, instead of an elastomeric liner in the valve body, to separate the flow stream from the closure element.
Working knowledge of cylinder valves
Working knowledge of cylinder valves can improve processes, save time and money, prevent problems, maintain the life and integrity of the valve, and improve the safety of your operation. This document must not be used as a valve modification or repair guide. No changes to valves are permitted, and any repairs shall only be made by or under the direction of the supplier.
