20FT ISO Cryogenic Tank Container

ISO Tank Container

20m3 lng iso tank container/cryogenic iso tank/ iso tank container
Our cryogenic tank containers are designed for the efficient, safe, and long-term storage of cryogenic liquefied gases (liquid nitrogen, oxygen, argon, and CO2).
Based on the double shells, vacuum-Perlite insulation design is available in capacities from 20FT and 40FT with working pressures of 8 bar, 16 bar, and 22 bar.

Tags, , , , , , ,
Categories
FacebookXPinterestRedditLinkedinWhatsappTelegram

ISO ASME Tank CONTAINER

China 20FT ISO Cryogenic Tank Container

DSW’s T75 Cryogenic Tanks are suitable for the intermodal carriage of nitrogen, oxygen, argon, LNG (Liquefied Natural Gas), C2H4 (Ethylene), and C2H6 (Ethane).

Model：1CC-TCS-20000/16                                     Insulation type： Multi-layer
NO Items Inner vessel Outer vessel
1 Design pressure     MPa 1.6 -0.1（outer）
2 Working pressure    MPa 1.6 -0.1（outer）
3 MAWP            MPa 1.6 /
4 Design temperature    ℃ -196 -19～50
5 Working temperature   ℃ ≥-196 normal
6 Pneumatic test      MPa 1.6 HLD
7 G. Vol              m3 20.8 5.5(interlayer)
8 E. Vol              m3 19.76 /
9 Medium LOX/LIN/LAR Multi-layer
10 Main material S30408 Q345R
11 Treatment Pickling and passivation Sanding and coating
12 Corrosion allowance  mm 0 0
13 Joint efficiency 1 0.85
14 Filling rate 95% /
15 Static evaporation   %/d ≤0.22(by LOX), ≤0.35 (by LIN), ≤0.24 (by LAR),
16 Seal off vacuum degree Pa ≤1×10–2
17 Leakage of vacuum interspace  Pam3/s ≤1×10–6
18 ISO code 22T7
19 Diameter         mm Φ2150 Φ2400
20 External Dimensions  mm 6058×2438×2591
21 type Horizontal
22 Tare weight           Kg ~7890
23 Fully loading weight    Kg ~15986(LIN), ~27585(LAR), ~22546(LOX)
24 Design service life 15years
25 Open pressure for safety valve 1.89Mpa
26 Sort Ⅲ
27 Portable tank guideline T75

China 20FT ISO Cryogenic Tank Container Stainless Steel ISO ASME Tank

Specifications for Cryogenic Tank Containers

304N Stainless steel inner and 304 outer shell, alternatively carbon steel outer vessel
High vacuum super insulation
Baffles
High-quality valves and instrumentation
Datalogging and telemetry options
Multiple loading and discharge configurations available
With or without a cryogenic pump
Stainless steel valve cabinet with lockable doors
Approved for intermodal operation according to IMDG, CFR49, ADR/RID, UIC, TIR, CSC, TC
20FT ISO Cryogenic Tank Container Stainless Steel ISO ASME Tank
20FT ISO Cryogenic Tank Container Stainless Steel ISO ASME Tank
DSW would supply a full range of transport and storage solutions for cryogenic air gases like nitrogen, oxygen, and argon (LIN/LOX/LAR), carbon dioxide (CO2), liquefied natural gas (LNG), and other gases.
