Cryogenic ISO Tank Container

Cryogenic ISO Tank

Cryogenic ISO tanks are versatile containers used to transport and store cryogenic gases in bulk.
Medium : LO2/LN2/LAR/LCO2/LNG/LN2O
Volume: 21.4 M3
Working pressure: 2.2 MPa
6058 X 2438 X 2591 mm
Material: inner: 1.4315
Shell: SA-516M Gr485
Net weight: 10,200kg
Vacuum pressure rate < 0.05 torr
make a place pump on the tank that at position,
+ Certificate of Portable Tank issue
by CSC (China Classification Society)
+ Tank container periodic Inspection Report issue
by LR (Lloy Register Group Limited)

ISO Tank CONTAINER

A portable ISO tank, also known as an ISO container, UN portable tank, or isotainer, adheres to the International Organization for Standardization (ISO) standards.
These specialized containers are designed to transport bulk liquids, both hazardous and non-hazardous.
The use of ISO tank containers is to transport and store non-hazardous and hazardous materials, such as liquids and powders.
ISO tanks are made of stainless steel with an insulation layer and a protective layer such as aluminum or polyurethane.
T75 tank containers are a secure and safe option for transporting many liquefied gases.
DSW offers onshore and offshore portable gas transport Solutions for nitrogen, oxygen, LNG, argon, methane, nitrous oxide, ethylene, carbon dioxide, and hydrogen.

1. Technical Spec. of ISO tank container



Model:1CC-TCS-20800/22                                     Insulation type: Multi-layer
NO Items Inner vessel Outer vessel
1 Design pressure     MPa 2.2 -0.1(outer)
2 Working pressure    MPa 2.2 -0.1(outer)
3 MAWP            MPa 2.2 /
4 Design temperature    ℃ -196 -19~50
5 Working temperature   ℃ ≥-196 normal
6 Pneumatic test      MPa 2.2 HLD
7 G. Vol              m3 20.8 5.15(interlayer)
8 E. Vol              m3 19.76 /
9 Medium LOX/LIN/LAR/LN2O Multi-layer
10 Main material SA240M304 Q345R
11 Treatment Pickling and passivation Sanding and coating
12 Corrosion allowance  mm 0 0
13 Joint efficiency 1 0.85
14 Filling rate 95% /
15 Static evaporation   %/d ≤0.22(by LOX), ≤0.35 (by LIN), ≤0.24 (by LAR),
16 Seal off vacuum degree Pa ≤1×102
17 Leakage of vacuum interspace  Pam3/s ≤1×106
18 ISO code 22T7
19 Diameter         mm Φ2150 Φ2400
20 External Dimensions  mm 6058×2438×2591
21 type Horizontal
22 Tare weight           Kg ~9100
23 Fully loading weight    Kg ~15986(LIN), ~26900(LAR), ~21835(LOX)
24 Design service life 15years
25 Open pressure for safety    valve 2.31Mpa
26 Sort
27 Portable tank guideline T75

ISO Standards

When manufactured, 20′ intermodal containers follow EN, ASME/DOT, or Chinese design standards. They offer maximum allowable working pressure (MAWP) options of 10, 18, and 24 bars in European designs and 100, 150, 180, and 230 psi in ASME/DOT designs. DSW’s intermodal containers are optimized explicitly for LNG and are suitable for high ethylene or ethane gas cargo payloads.

Sizes and Applications

Cryogenic ISO tanks come in various sizes, catering to storage and transportation needs.

ISO Tank 20 feet:
Capacity: Typically around 20,000 liters (20 cubic meters).
Applications: Used for transporting and storing cryogenic liquids such as liquid oxygen, liquid nitrogen, and liquid argon.
Features: Resistant to harsh weather, easy to load and unload.

ISO Tank 20 feet (Side Opening door)
DAG.NO Design Code MAWP(MPa) Capacity(m3) Tare Weight(kg) Load weight(kg) Rated weight(kg)
CASIS-20-1.6-S ASME 1.6 21.1 7500 28500 36000
CASIS-20-1.8-S ASME 1.8 21.1 7800 28200 36000
CASIS-20-2.4-S ASME 2.4 21.1 8800 27200 36000
CENIS-20-1.8-S EN 1.8 21.4 8600 27400 36000
CENIS-20-2.4-S EN 2.4 21.1 10000 26000 36000
20ft Cryogenic Tank Container (Back Opening door)
DAG.NO Design Code MAWP(MPa) Capacity(m3) Tare Weight(kg) Load weight(kg) Rated weight(kg)
CASIS-20-1.6-B ASME 1.6 20.2 7200 28800 36000
CASIS-20-1.8-B ASME 1.8 20.2 7550 28450 36000
CASIS-20-2.4-B ASME 2.4 20.2 8400 27600 36000
CASIS-20-3.5-B ASME 3.5 20.2 10250 25750 36000

ISO Tank 40 feet:
Capacity: Approximately 40,000 liters (40 cubic meters).
Applications: Similar to the 20-foot container, but with a larger capacity.
Features: Suitable for bulk transportation of cryogenic liquids.

10-foot ISO Tank Container:
Capacity: Around 10,000 liters (10 cubic meters).
Applications: Smaller-scale transport and storage of cryogens.
Features: Versatile and compact.

10ft OFFSHORE Cryogenic Tank Container
DAG.NO Design Code MAWP(MPa) Capacity(m3) Tare Weight(kg) Load weight(kg) Rated weight(kg)
CASIS-10-0.6 ASME/GB 6bar 7.62 5300 5900 11200
CASIS-10-2.2 ASME 22bar 7.8 7800 8700 16500

T14 ISO Tank Container:
Capacity: Varies, but typically used for hazardous and non-hazardous liquids.
Applications: Suitable for various liquid cargoes.
Features: Insulated 316L stainless steel construction.

T75 ISO Tank Container:
Capacity: Designed specifically for cryogenic liquids.
Applications: Transporting liquefied gases like liquid nitrogen, liquid oxygen, and liquid argon.
Features: Insulated and suitable for intermodal transport.

Cryogenic Liquid ISO Tank Container

Portable Cryogenic ISO Containers

LNG, Ethane, Ethylene, Nitrogen, and Argon.
The DSW comprises a cryogenic tank and associated pipework and valves enclosed within a durable frame designed and certified to comply with DNV and EN specifications.
This unit can be handled using forklift pockets or slings attached to frame pad eyes.

Tanks manufactured to operate between 60 psig and 250 psig are also available with ASME certifications.
The DSW features high vacuum super-insulation, full decals (customers may provide logos if desired), a pressure build system, and various pipework options for maximum versatility.

Custom painting on special request.

20m3 Cryogenic Liquid ISO Tank Container

T75 UN tank container

This T75 UN tank possesses approvals for road, rail, and sea transport, CSC with DNV and EN approvals, and many other options. Designed and manufactured to transport liquid nitrogen, argon, and oxygen for storage/transport to oil production platforms worldwide from offshore supply vessels – typically, CO2-format tanks can even come equipped with a working pressure of 24 bar.
The 10ft ISO tank can accommodate working pressures ranging from 3.0 to 24 Bar.
20m3 Cryogenic Liquid ISO Tank Container
Liquid nitrogen, oxygen, argon, and CO2 ISO TANK CONTAINERS, Based on the double shells,vacuum-Perlite insulation design is available in capacities from 20FT and 40FT with working pressures of 8 bar, 16 bar, and 22 bar.
