Ethylene oxide Mixture with CO2 (C2H4O + CO2 )

Ethylene Oxide Mixture with CO2 (C2H4O + CO2 )

EO 80%:CO2 20%
25KG gas filling in 40L cylinder
20kg EO gas 5kg CO2kg
EO purity >=99.99%
CO2 purity >=99.95%Ethylene Oxide (ETO) is a common gas used for low temperature sterilization.

Ethylene oxide Mixture with CO2

CARBON DIOXIDE AND ETHYLENE OXIDE MIXTURE, WITH MORE THAN 9% BUT NOT MORE THAN 87% ETHYLENE OXIDE
A carbon dioxide and ethylene oxide mixture is a combination of two gases: carbon dioxide (CO2) and ethylene oxide (C2H4O).
It is a colorless gas with an ether-like odor. Carbon dioxide is noncombustible.
Ethylene oxide is flammable. The mixture can asphyxiate by displacement of air. Under prolonged exposure to fire or intense heat the containers may rupture violently and rocket. It is used as a fumigant.

The mixture can asphyxiate by displacement of air, meaning it can reduce the amount of oxygen available if it leaks into an environment.
It’s important to note that under prolonged exposure to fire or intense heat, containers holding this gas mixture may rupture violently and rocket.

This mixture is used as a fumigant, which means it’s employed to disinfect or purify an area by filling it with fumigant gas.
However, due to the properties of ethylene oxide, such as being highly flammable and a health hazard, it’s crucial to handle this mixture with extreme care and follow all safety guidelines.
Ethylene oxide is also known to be a carcinogen, so safety measures are paramount when dealing with this substance.

Ethylene oxide Mixture with CO2 (C2H4O + CO2 )

Sample Name Sterilization gas Ingredient Ethylene oxide, carbon dioxide
Production Date 2018/06/06 Analysis Date 2018/06/06
Cylinder Type 40L cylinder cylinder No. 18R06135
Net Contents 25kg Shelf Life One year
Test Items
Items Result
Purity
C2H4O >=99.99%
CO2 >=99.95%
C2H4O:CO2=80:20

Ethylene oxide Mixture with CO2 (C2H4O + CO2 )

DSW offers an ethylene oxide-carbon dioxide mixture in various purity and concentrations.

Ethylene Oxide “Gas” Sterilization. ETO is a colorless gas that is flammable and explosive. The four essential parameters (operational ranges) are gas concentration (450 to 1200 mg/l, temperature (37 to 63°C, relative humidity (40 to 80%)(water molecules carry ETO to reactive sites), and exposure time (1 to 6 hours). It is most commonly mixed with CO2 as sterilization gas and used to sterilize instruments with long lumens, such as endoscopes and all materials that must be fixed but cannot withstand higher temperatures.

Additional information

Condition:

New

Brand Name:

JP brand

Machinery Test Report:

Provided

Warranty of core components:

Not Available

Dimension(L*W*H):

229*1485mm

Weight:

56kg

Inner Material:

34CrMo4

Design Pressure(MPa):

30Mpa

Design Standard:

ISO9809-1:2010

Warranty:

3 months

Key Selling Points:

High Productivity

After Warranty Servi

Online support

Showroom Location:

None

Working Pressure:

200bar

Outside Diameter:

229mm

Place of Origin:

Zhejiang, China

Video outgoing-inspection:

Provided

Marketing Type:

Pressure vessel

Capacity:

10M3

Volume (m³):

0.057M3

Outer Material:

34CrMo4

Max Working Pressure(MPa):

20 MPa

Working Temperature(℃):

-20 – 60 ℃

After-sales Service Provided:

Video technical support

Applicable Industries:

Hotels, Manufacturing Plant, Restaurant, Home Use, Food Shop,

Local Service Location:

None

Water Capacity:

50L oxygen Cylinder

Test Pressure:

300bar Oxygen Gas Cylinder
